November 14, 2024

DREDGES FOR SALE

For additional information please contact Anthony Iorio at Tel (516) 536 7375 - rigs@sunmachinery.com

105’ x 50’ x 8’, Bucyrus Erie 88B crane with 12 Cubic Yard bucket, (2) 30” x 65’ square spuds, (2) H50 Pullmaster winches, 20 KW John Deere generator, set up with weighted spud tension system, will sell crane and dredge separately Price: $3,200,000

8” X 8” DSC MORAY DREDGE (Ref#4185c)

42.8’L x 18.5’W, 17.5’ depth, 42,000 lb overall weight, 19.5” impeller dredge pump, 25 hp cutter power, cylinder ladder lift/swing, 8” square spud, articulating rear spud, Cat 275 hp diesel engine, inline direct marine style transmission for dredge pump reduction, PLC operating system, standard equipment, power up/down winches for proper cable storage, stern kicker spud or extending leg for controlled positioning, located Florida Price: $300,000

*8” MORAY DREDGE (Ref#4155d) Built by Dredge & Supply in 2000, Cat engine, submersible pump, needs sandblast and paint, hull in good condition, located Midwest US Price as is: $90,000

MUDCAT SP915 8” AUGER DREDGE (Ref#4191)

15’ depth. 32’ length. Detroit 6 cylinder. 8” discharge. Cutter head width: 98". Capacity: 2000 gallons per minute. Thomas pump. Replaced main gear box – rebuilt box $30k, Located Pennsylvania Price: $80,000

SRS CRISAFULLI SD110 AUGER DREDGE (Ref#4056)

Manufactured 2012, 1400 hours, Perkins 110 hp engine, 1200’ of 6” solid dredge pipe, 300’ floating pipe, used in fresh water only, currently on land in Ohio (new cost $360,000) Price: $265,000

SRS CRISAFULLI SD110 AUGER DREDGE (Ref#4131)

Manufactured 2010, Perkins 110 hp engine (dredge has 640 hours), Yamaha 116 hp engine (approx. 270 hours), sitting since 2017, excellent shape
2012 Kearney trailer for piping with approx. 500’
2004 Hillsboro trailer for dredge
Located Iowa
Price: $150,000

8” MUD CAT 115D DREDGE (Ref#3815)

Built 2020, low hours, positioning boom with 15’ digging depth, heavy duty steel hull, 8” Hardox steel submersible dredge pump closed face impeller 125hp John Deere diesel engine, dual 25 hp Yamaha outboard with throttle control self-propulsaion system.
810’ of 8” SDR HDPE pipe
45’ 8’ flat discharge hose
(23) IMS Saddle type pipe/hose floats
Used for one job, excellent condition, on land in Minnesota
75 yards per hours in sludge type material
Price: $250,000

MUD CAT 115D DREDGE (Ref#3731)

Built 2020, used very little (less than one week), 15’ working depth, 8’ cut width, 17” cut height, 22.5” avg draft, Catamaran hull type, John Deere 125 hp engine, 60 gal fuel capacity, MudCat slurry pump with 8” discharge, 3000 gpm max performance, 3.5” solids passage (closed impeller), 4.3” solids passage (open impeller) Price: $240,000

8” VMI 815 AUGER DREDGE (Ref#4069)

Built 1998, Warman ladder mounted 8” pump, 350 hp Cummins M11 engine with 3500 hours (recently rebuilt). Recently invested $150,000 into the dredge including: rebuilt engine, all new hydraulics, all new hoses, all new wiring, all new dredge steel and flex hose piping, brand new cutterhead, teeth and shroud and protective cage, rebuilt dredge pump with new impeller, structural and hull work. Located Texas Price: $110,000

8” VMI 615 HNE MINI DREDGE (Ref#4146)

Built 1996, 8” discharge, electric powered (150’ power cable included) 480V, approx. 240’ hose, cable driven, used in fresh water only at municipal facility pond, 44’ x 11’W, located Nevada Price: $50,000

6” CUSTOM HYDRAUILC SUCTION DREDGE (Ref#4203)

Gulf Atlantic 6” dredge pump mounted on a custom galvanized dredge arm, 10’ digging depth, can be upgraded to an 8” pump, John Deere hydraulic power unit powers the hydraulic pump. TB290 excavator mounted on barge chassis through the deck, hull 34’ x 12’+, good condition, highly maneuverable and transportable, lift pad eyes, The barge features a robust frame construction suitable for operation in shallow water, maneuverability is achieved with precision using the dredge arm and winch powered spuds, includes 400’ dredge pipe, floating gear and galvanized 25 yard dewatering bin, good condition, located in Florida Price: $250,000

*6” X 6” VMI AUGER DREDGE (Ref#4155a) Uses 8” dredge pipe, 20’ depth, 8’ wide auger, ladder mounted 6” x 6” pump, 350 hp Cummins engine (rebuilt out of frame), never used in salt water, located Midwest USA Price: $75,000

*8” MUDCAT AUGER DREDGE (Ref#4155b) Mudcat pump, 19’ depth, 8’ wide auger, located Midwest US Price: $65,000

8” MUD CAT AUGER DREDGE (Ref#3917) Manufactured 2005, 2500 hours, 20’ depth, 24” x 96” auger, 8” submersible pump, can produce 228 gpm @ 140’ head, Cat 275 hp diesel engine, New York Price: $75,000

8” CUSTOM BUILT DREDGE (Ref#4140)

8” discharge, 7’ cutter on 21’ elevator (part that moves while cutting), will produce one yard a minute in sandy/silty (not heavy rock) material and will push out at zero elevation 2100’, 2023 Twin 90 hp Yamaha engine, 8’ custom built self-propelled, enclosed cab, with 30’ gooseneck trailer, located Georgia Price: $125,000

10” SWINGING LADDER BARRACUDA CUTTERHEAD SUCTION DREDGE (Ref#4152)

25’ ladder length, 66’l x 17’10”w (with side tanks), 4’ depth, 10’ height (spuds removed), 30” mean draft (with fuel), 10” spud length, digging depth 2’ – 19’, maximum swing (swinging ladder mode) 19’ – 26’, maximum swing conventional mode 76’ x 87’. Cat 3406 KITA engine, Murphy EL-150-K1 day tank sender, R.R. 1000DF cutter gear 71,900 in/lb torque, Cutter’s Edge 5 blade left hand 31’ ½ ID, Fairfield reduction gear 8:1 ratio, Pullmaster winches, 12 x 10 dredge pump, well maintained, currently on landing repairing where needed and painting, located East Coast US Price: $425,000
Available at extra cost:
8500’ of 10” and 12” dredge pipe in excellent condition on trailers, McElroy Fuser and 10” booster

10” x 10” x 30” CUTTERHEAD DREDGE (Ref#4170)

Metso 10” x 10” pump, driven by Cummins KT1150 diesel engine, 40’ ladder, 36” cutterhead, Cummins 855 diesel engine power pack to operate deck winches and cutter head, spud wells (no spuds), enclosed cab with gauge package and vacuum gauge, approx. 400’ of 12” discharge pipe, recently worked, located Southern US Price: $99,500

12” x 10” ELLICOTT 370 DREDGE (Ref#4128T)

Built 1984, 36’L x 12’W x 4’ depth, Dredge pump engine Cat 3406, 31.5” cutter diameter w/5 blades, 40 HP, 0-39 rpm, 3840 lb cutting force, 195 lbs/in, (2) swing wiches 8000 lb, 22’ ladder, 16’ digging depth at 45 degrees, 20’ digging depth at 60 degree, 57.5’ overall length, 2000’ of flanged 10” HDPE dredge pipe and (40) 10” pipe floats, located Washington State Price: $275,000

*10” CONVENTIONAL DREDGE BUILT BY DREDGE & SUPPLY (Ref#4155c) 12” suction, 10” discharge, Pierce pump, Cat 3406 engine, 30’ ladder (removed but will reinstall), uses 12” dredge pipe, never used in salt water, two owner machine, side tanks to make 18’ wide (removable for transport), located Midwest US Price: $150,000

Available at extra cost: 400’ of used 12” SDR17 HDP dredge pipe (60-90%)

12" x 10" ELLICOTT 370 DREDGE PACKAGE (Ref#4086)

Includes Ellicott 370 dredge Cat 3406 engine (Motor has been refurbished with low hours), 10 x 12 booster pump (pump has new sleeve and impeller is in great shape), 1800’ dredge pipe, pushboat with Twin Detroit engines, 6’ x 15’ barge with 14’x8” spuds, 700 gal fuel tank, McElroy fusion machine for fusing pipe w/ shoes for 8”-12” and 18”-20” pipe. Extra new Maddox 8” x 8” pump and gearbox, many other extras and spares. Well maintained and in excellent condition. Located Nebraska Package Price: $275,000

10” x 8” MUD CAT MC2000 AUGER DREDGE (Ref#3618)

Built 2004. 10" suction, 8" discharge, 6" particle clearance. Engine: John Deere 6081 H 300 HP. Length overall: 47, width overall 8'6", height overall: 8'6". Dry weight: 28,300lb. Draft 2.5' fully loaded. Main pump: Ellicott 24" impeller, capacity: 2500 gpm @ 162' TDH. Sludge pump: Ellicott 25" impeller, 10" suction, 8" discharge, 8" particle clearance. Propulsion: Triple wrap friction drive winch. 2300lbs line pull, 50 fpm max speed. Used in the same freshwater pond since it was new, never in saltwater. 2690’ of 8” HDPE SDR 17 dredge pipe, 1 rubber discharge hose, float for discharge hose. Located Northeast US. Price dredge only: $170,000 Package Price: $205,000

MUDCAT MC2000 AUGER DREDGE (Ref#3608)

stock photo

4 available from 1999 – 2005, 272 hp Cat engines, the 2001 unit has a Tier 3 Cummins engine with 2500 hours, 24” diameter auger, 20,000 lb torque, 20’ depth, forward/reverse digging, currently on land, located New York Price: $65,000 each

IMS MODEL 7012 HP DREDGE (Ref#4000)

Approx 1600 hours on meter, GIW LCC-M 10” x 12” dredge pump, 500 hp John Deere diesel/hydraulic power unit, positioning boom with 30’ digging depth, hydraulic sand and silt cutterhead with replaceable teeth, Starwheel drive self-propulsion system, enclosed operator’s cab, located Midwest US Price: $525,000

IMS 7012 VERSI-DREDGE PACKAGE (Ref#3627)

Completely reconditioned 2020 with 2700 hours, all major rework to bring it back to excellent condition. 51'5" x 12' x 10'5" high. Dry weight 47,700lbs. John Deere diesel 6135 AFM85, 13.5L 500 HP main engine with 2,650 hours. Fuel capacity 400 gal. (2) pontoons, 45" x 43" x 468". Draft 35". Working capacity: 11'6" cutter, working depth 30'. Dredge pump: GIW 10" x 12", 5,000gpm at 125' TDH with 2,000' discharge length. Starwheel self-propulsion system.
Package includes:
GIW 10" x 12" Boosters pumps, with 2,000 hours.
Located Florida
Package Price: $675,000

10" x 10" IMS 4010 AUGER DREDGE (Ref#3006)

Built 1991, 38'6" x 9'7" x 9'4", weight 22,000lbs. (2) 35" x 38" x 309" pontoons. Draft 30". Working capacity: Cut 96" wide x 22" deep. Working depth 20'. Engine: Cummins 5.9 177HP, Vickers 3525 hydraulic pump, 2500 gpm slurry pump. Fuel capacity: 180 gal, fuel consumption 13.2 gal/hr. Auger head, cable system. 10" suction, 10" discharge. Used in fresh water. Not used for 1 1/2 years. Located Nebraska. Price: $85,000

10” X 12” DSC BARRACUDA SWINGING LADDER DREDGE (Ref#4113a)

Built 2005, 2022 Cat C15 engine, 3’-17’ digging depth, 55’ overall length (with ladder), 17’10” overall width (operational mode), 4’ hull depth, 12’ heigh (less spuds), 38” mean draft (with fuel), 11’11” width (trucking mode), (2) spuds 28’ (1145 lbs) and 30’ (1225 lbs), 70,000 lb total dredge dry weight (approx.).
3’-17’ digging depth,
Swinging ladder - Maximum cut at minimum depth 26’, Maximum cut at maximum depth 19’
Conventional – Maximum cut at minimum depth 80’, Maximum cut at maximum depth 70’
Cat C15 engine, 2828 lb cutting force, 68,000 in/lb operating torque, 88 lb/in cutting force, 28” cutter diameter, 3” shaft diameter, 35 hp cutter rating, 0-32 rpm cutter speed.
Winches: 9617 lb pull (1st layer), 40 ft/min line speed, ½” wire, 208’ drum capacity
Hoist cylinder: 25,535 lb extending force, 41,233 lb retracting force
12” x 10” dredge pump with 32” impeller
Hoist winches: 2204 lb line pull, 81/ft/min, 3/8” wire, 83’ drum capacity
24 VDC battery, 321-645 Delco alternator
800 gal fuel capacity, 150 gal hydraulic oil capacity, operator’s charge, lighted ring buoy, handrails and kick rails, guards, early warning alarm system and engine shut down system, cabin lights, electric bilge pump, replaceable edge cutter, dredge pump priming system, dredge washdown system, high capacity service pump, hydraulic pump/engine clutch disconnect, pump/engine reduction gear, stern pulling eyes,
last used October 2023 Price: $525,000

14" x 12" AAMCO CUTTERHEAD DREDGE (Ref#2787a)

Reworked 2013 / Repowered 1995, Hull rebuilt / refurbished 2014, 65' x 24' x 5', draft 3', 7000 gal fuel capacity. 700 HP CAT 3412 Pump engine, GIW dredge pump, 14" Suction, 12" Discharge. 300 HP Cat 3306 Aux engine, 150 HP Cutterhead drive, 40' Ladder. (2) 16" x 50' stern spuds raised and lowered via winch. (2) 16" x 50' mooring spuds, self-raising and lowering. Hydraulic pumps, motors, cylinders, controls, valves, piping, hoses, and fendering. Firefighting equipment. On blocks, stored on land, excellent condition. Located Northeast USA, in the water. Price: $475,000

14” x 12” EAGLE IRON CUTTERHEAD DREDGE (Ref#4066)

60’ chain ladder 9” pitch, Mobile pully pump w/Cat 3406b (low hour), the two are connected together (can be splut up or sold together, used in fresh water in Texas Price: $325,000

*14” x 14” SHARK CUTTERHEAD DREDGE (Ref#4155e) Built by Dredge & Supply in 2000, 60’ ladder, Cat 3406, needs steel work on side tanks (not below water line), hull in good condition, located in Florida Price: $145,000
Available at extra cost: 4000’ 14” SDR17 DHP dredge pipe Price: $21 per foot

16” ELLICOTT DREDGE (Ref#3948b)

Cat 3508 (low hours), 62’ ladder, 52” cutterhead, 95’ x 24’ x 6’ hull, (2) 48’ spuds, 3 cabins, one bath, 4 beds, office, galley, 150 kw John Deere generator, 150 kw Cummins generator downstairs, located Louisiana, currently being reworked and modernized Price to be Determined

16” x 16” MADDOX BOOSTER PUMP (Ref#4050)

Detroit 12V92TI diesel engine, mounted on skid, complete, no fuel tank, located Florida Price: $65,000

ELLICOTT SERIES 2070 DRAGON 20” X 20” HYDRAULIC CUTTER SUCTION DREDGE (Ref#4062)

20” suction pipe, 20” discharge pipe, 50’ depth, 110’10” L (with ladder raised), 72” hull length x 26’6”W x 7’6” hull depth, 3 pontoons, 4.5’ hull draft (not including spuds), 9000 gal fuel capacity, 335,521 lb dry weight, main engine Cat C32 marine 1300 hp Tier 3 with heat exchanger, Aux engine Cat C15 440 hp tier 3 with heat exchanger, 1740 hp (not including genset), 250 hp at cutter shaft, 54” diameter cutter with 14,900 lb cutting force 18-27-36 rpm. 24” x 66’2” spuds Price: $2,500,000

20” INLAND CUTTERHEAD DREDGE (Ref#3914)

55’ dig depth, 70’ Ladder length, 155’ Length x 34’ breadth x 6.75’ depth, 5’ operating draft, main engine EMD 16-645 (2000 hp), 200 HP hydraulic cutter, HPU Cat 3408, (2) 500 kw Cummins KTA 19 Onan AC generator sets, Pullmaster 50 swing winches, Pullmaster 50 ladder winch, Braden 50 ton spud winch, 24” x 50’ spuds, 48,000 gal fuel capacity, fire detection system, to be sold out of USA Price: $4,600,000

GIW 10" x 12" BOOSTER PUMPS (Ref#3627b) (2) Available. One with 60 hours, one with 2,000 hours, Rocky Mountains. Price each: $165,000

*14” X 14” PIERCE BOOSTER PUMP (Ref#4155f) 700 hp Cat engine, located Midwest US Price: $95,000

*12 x 12 PETTIBONE BOOSTER PUMP (Ref#4155g) 12V71n Detroit diesel engine 450 HP. Pettibone pump, could use new impeller, turns at 600rpm, new transmission, Located Midwest US Price: $60,000

16” SDR 17 Dredge Pipe (Ref#3569) 12,000 LF (saw cut to 40’-50’ lengths, some with couplings) Price: $13 per ft

*4000’ 14” SDR17 HDP dredge pipe (Ref#4155i) Price: $21 per foot

12” DREDGE PIPE (Ref#3941)
6800’ of 12” HDPE SDR17 dredge pipe, cut ends, 40’ lengths, some connectors $14 per foot
2800’ new 12” HDPE SDR17 dredge pipe, factory cut ends, 40’ lengths $22 per foot
3000’ 8” HDPE SDR 17 dredge pipe with connections, like new, loaded on truck $13 per foot

12” SDR 17 DREDGE PIPE (Ref#4113b) approx. 10,000’ Price: $13 per foot

12” SDR11 DREDGE PIPE (Ref#4113c) approx. 5000’ Price: $13 per foot

*500 KW CATERPILLAR GENSET (Ref#4155h) 900 hours, serviced, Cat 3412 engine, located Midwest US Price: $50,000

The listings with * are all at one location.

See more dredges for sale on our website: dredges for sale. Let us know if you have any dredges or dredge equipment for sale.
